Megafence 3D Panel Fence: Uniting Security and Aesthetics with Versatility
Introducing Megafence, where we blend security and aesthetics with our high-quality 3D Panel Fence series. With 50 x 150 mm spacing and various wire thicknesses (Ø 4.00 mm – Ø 4.20 mm – Ø 4.50 mm – Ø 5.00 mm and Ø 6.00 mm), our fences offer both durability and an elegant solution.
Superior Materials and Production
Our panels are crafted from high-quality galvanized wires and coated with electrostatic powder paint after the manufacturing process. This ensures the longevity of our fences, providing resistance against various weather conditions.
Color Options
Megafence offers a wide range of color options for personalizing your fences. In addition to commonly preferred colors like RAL6005 (Moss Green) and RAL7016 (Anthracite Grey), we provide customization options based on your desired RAL color code.
Versatile Design
Megafence provides the option to choose between double bars or single bars in the bends of the fence. This versatile design allows you to customize the appearance of your fence based on your preferences.
Various Application Areas
Megafence 3D Panel Fence delivers security and aesthetics in various application areas:
Home and Site Security: Enhancing security and providing an aesthetic look for home and site enclosures.
Industrial Facilities: Preferred for security purposes in factories, warehouses, and industrial facilities.
Public and Commercial Spaces: Utilized for restriction and security in school surroundings, parks, and commercial areas.
Megafence 3D Panel Fence puts your security at the forefront while contributing an aesthetic touch to your surroundings. With its versatile design, durability, and color options, our fence stands out as a flexible solution for all your needs.
Technical Details
| Product Type | 3D – Megafence Panel Fences |
| Vertical Wires | Ø 4,00 – Ø 4,20 – Ø 4,50 – Ø 5,00 – Ø 6,00 mm |
| Horizontal Wires | Ø 4,00 – Ø 4,20 – Ø 4,50 – Ø 5,00 – Ø 6,00 mm |
| Mesh Size | 50 x 150 mm ( +/- % 5 ) |
| Wires In Bends | Single Or Double Wires |
| Raw Material | Hot Dipped Galvanized Wire |
| Galvanize Rate | 50-90 gr/m² |
| Finishing | Electrostatic Powder Paint |
| Powder Paint | JOTUN |
| Colors | Hot-Dip Galvanized |
| RAL 6005 Moss Green | |
| RAL 7016 Anthracite Grey | |
| Any RAL Color Upon Request | |
| Available Heights | 500 mm |
| 750 mm | |
| 1000 mm | |
| 1200 mm | |
| 1500 mm | |
| 1700 mm | |
| 2000 mm | |
| Available Lengths | 2000 mm |
| 2500 mm | |
| Fence Post Profile | 50 x 50 x 1,50 mm or 2,00 mm H.D.G. Profile |
| 60 x 60 x 1,50 mm or 2,00 mm H.D.G. Profile | |
| Base Plate ( Flange ) | 120 x 120 x 4,00 mm |
| Anchor Bolts | M10 x 85 mm |
| Fence Clips | Metal Or Plastic |
| Screws | Self Drilling Screws |
| Post Caps | Plastic |
| Warranty | 10 years against corrosion |
| Packaging | 50 Panels / Pallet |
Details of Megafence
